Separator Design
Use an effective separator design (dual separator design with a vertical and horizontal separator),
optimizing gas/liquid separation.
Accuracy & Metering Range
- Water cut range 0-100%.
- Sampler water cut accuracy – 0.25% absolute.
- Gas flow accuracy – 2.0%.
- Liquid flow accuracy – 1%.
- Liquid range: 10 – 12,000 Bbl./day.
Water Cut
- Determined using Coriolis meter densities and isokinetic sampler.
- Composite samples per test period with volume-weighted average.
- Sampling aligned to recognized petroleum measurement standards.
Operating System
PLC-based control with SCADA for HMI. Results can be trended and exported to Excel.
System Benefits
- Diagnostics analyzed to assure quality before submission.
- On-board lab support for water cut analysis.
- HSE equipment and detectors supported based on site needs.
- Self-contained unit; minimal resources required from customer.
